MO-142D
| Внешний вид | .SLDPRT model, info | Description |
|
 MO-142D MO-142D
|
Thin Small Outline Package (Type I). 0.5 mm Pitch, 1.2 mm Max Height. S-PDSO-G/TSOP. Item 11.1-583E |
MO-142D Variations, STEP models
| JEDEC Name | IPC-7351 Footprint | Description |
 MO-142.AA | TSSOP50P1400X120-24 | 24-leads, (12.6 x 6.2) mm Body Size |
| MO-142.AB | TSSOP50P1600X120-24 | 24-leads, (14.6 x 6.2) mm Body Size |
| MO-142.AC | TSSOP50P1800X120-24 | 24-leads, (16.6 x 6.2) mm Body Size |
| MO-142.AD | TSSOP50P2000X120-24 | 24-leads, (18.6 x 6.2) mm Body Size |
| MO-142.BA | TSSOP50P1400X120-32 | 32-leads, (12.6 x 8.2) mm Body Size |
| MO-142.BB | TSSOP50P1600X120-32 | 32-leads, (14.6 x 8.2) mm Body Size |
| MO-142.BC | TSSOP50P1800X120-32 | 32-leads, (16.6 x 8.2) mm Body Size |
| MO-142.BD | TSSOP50P2000X120-32 | 32-leads, (18.6 x 8.2) mm Body Size |
| MO-142.CA | TSSOP50P1400X120-40 | 40-leads, (12.6 x 10.2) mm Body Size |
| MO-142.CB | TSSOP50P1600X120-40 | 40-leads, (14.6 x 10.2) mm Body Size |
| MO-142.CC | TSSOP50P1800X120-40 | 40-leads, (16.6 x 10.2) mm Body Size |
| MO-142.CD | TSSOP50P2000X120-40 | 40-leads, (18.6 x 10.2) mm Body Size |
| MO-142.DA | TSSOP50P1400X120-48 | 48-leads, (12.6 x 12.2) mm Body Size |
| MO-142.DB | TSSOP50P1600X120-48 | 48-leads, (14.6 x 12.2) mm Body Size |
| MO-142.DC | TSSOP50P1800X120-48 | 48-leads, (16.6 x 12.2) mm Body Size |
| MO-142.DD | TSSOP50P2000X120-48 | 48-leads, (18.6 x 12.2) mm Body Size |
| MO-142.EA | TSSOP50P1600X120-56 | 56-leads, (14.6 x 14.2) mm Body Size |
| MO-142.EB | TSSOP50P1800X120-56 | 56-leads, (16.6 x 14.2) mm Body Size |
| MO-142.EC | TSSOP50P2000X120-56 | 56-leads, (18.6 x 14.2) mm Body Size |
